දිගු අත් කඩදාසි රෝල් කලම්ප බෙදන්න

නිවස / සියලුම ඇමුණුම් / දිගු අත් කඩදාසි රෝල් කලම්ප බෙදන්න

දිගු අත් කඩදාසි රෝල් කලම්ප බෙදන්න

නිෂ්පාදන වාසි


3.0ton forklift attachment split long arm paper roll clamps equipment with China Xinchai C490 engine, hydraulic transmission,USA EATON hydraulic assisted steering valve,SHIMADZU oil pump,full suspension chassis.It is widely used to handing all kinds of goods,such as pallet,steel,brick etc.Shantui has cooperated with KOMATSU more than 30 years,all the product was made under KOMATSU standard.

එන්ජිම
ආකෘතිය
හුමායි සී 490
ශ්‍රේණිගත ප්‍රතිදානය
40/2650
Kw / rpm
ශ්‍රේණිගත ව්‍යවර්ථය
165/1800
N · m / rpm
සිලින්ඩරයේ අංක
4
බෝර × ආ roke ාතය
90 × 105
මි.මී.
අවතැන් වීම
2.7
එල්
මාන
උස එසවීම
3000
මි.මී.
LxWxH (දෙබලකින් / රහිතව)
3779 (2709) x1226x2140
මි.මී.
හැරවුම් අරය
2450
මි.මී.
මාස්ට් ඇලවීමේ කෝණය (F / R)
6/12
උපාධිය
කාර්ය සාධනය
ගමන් වේගය (සම්පූර්ණ බර / බරක් නැත)
19/20
කි.මී.
බර පැටවීම (සමඟ / රහිතව) ඔසවන්න
420/450
mm / තත්
Max.gradeability
20
%
ස්වයං බර
4560
Kg
රෝද සහ ටයර්
ඉදිරිපස
28 × 9-15-14PR
පසුපස
6.50-10-10PR
රෝදපුටුව
1700
මි.මී.
අවම බිම් නිෂ්කාශනය (මාස්ට්)
110
මි.මී.

වීඩියෝ


ඉක්මන් විස්තර


තත්වය: නව
Place of Origin: HUAMAI, China (Mainland)
වෙළඳ නාමය: හුමායි
වර්ගය: බලැති පැලට් ට්‍රක්
පවර් සූස්: ඩීසල් එන්ජිම
ශ්‍රේණිගත පැටවීමේ ධාරිතාව: 3000kg
උපරිම. එසවීමේ උස: 8000 මි.මී.
අවම එසවුම් උස: 3000 මි.මී.
දෙබලක දිග: 1070 මි.මී.
දෙබලක පළල: 122mm
සමස්ත මානයන්: 3829x1226x2140mm
සහතික කිරීම: ISO9001 / ISO14001 / CE
අලෙවියෙන් පසු සේවාව සපයනු ලැබේ: විදේශයන්හි සේවා යන්ත්‍රෝපකරණ ලබා ගත හැකි ඉංජිනේරුවන්
Accseeory: multiple load handlers
Paper Roll clamps: China BRAND
Weight OF accessories: 650KGS
Rotatation: 360 degree
MOUNT CLASS: 3 stage
Roll range: 200-1300mm
TYPES: Fixed short arm
Pad type: optional
Pressure: 35-160ba
Loading Capacity: 2ton


Split long arm paper roll clamps are specialized attachments used for handling and transporting large rolls of paper. They attach to a forklift and hold the rolls securely in place, allowing the operator to easily pick up, move, and place the rolls.

The split long arm paper roll clamps consist of two arms that attach to the forks of the forklift and a clamp mechanism in the center. The arms are designed to split apart, making it easier to place the rolls in the desired position. The clamp mechanism is designed to securely hold the rolls in place, reducing the risk of injury and damage to the load and the environment.

One of the main advantages of the split long arm paper roll clamps is their versatility. They can handle a wide range of large rolls of paper, making them a convenient accessory for a variety of material handling tasks. The split arms also make it easier to transport the rolls, reducing the risk of injury to the operator and other workers.

Another advantage of the split long arm paper roll clamps is their efficiency. They make it easier to handle and transport the rolls, reducing the time and effort required to complete the task. This makes them more cost-effective and time-efficient, saving companies time and money in the long run.

In conclusion, split long arm paper roll clamps are a useful tool for handling and transporting large rolls of paper. They are versatile, efficient, and cost-effective, and are an essential tool for companies that handle heavy loads on a regular basis.

,
